Details

---

⭐️FEATURES⭐️
▪️ Cost saving
- Inverter control system
- High efficiency
- Energy saving
- Long life of parts

▪️ Safety
- Compliance with IEC 60974-1 standard
- Compliance with Industry 4.0

⭐️SPECIFICATIONS⭐️
- Model : SMAW170HD
- Voltage : 1 Phase AC240V ±15%
- Frequency : 50/60hz
- Rated Input Voltage : 32V
- No-Load Voltage : 70V
- Output current : 30-170A
- Rated Output Voltage : 26.8V
- Hot start : 1-100A
- Force adjusting ange : 1-10A
- Duty Cycle : 30%
- Electrode diameter : 6013 : 2.0 ~3.2MM
                                   7018 : 2.0 ~3.2MM
- Plate thickness : 2.0 ~ 5.0MM
- No-Load loss : 40W
- Efficiency : 80%
- Power factor : 0.73
- Insulation grade : F
- Housing Protection Grade : IP21
